件号 | 规格(") | L(mm) |
A (mm) |
B (mm) |
D (mm) |
I (mm) |
T (mm) |
J (mm) |
包装 |
91-588-1-22 | 8x9 | 128 | 16.8 | 20.2 | 8.7 | 6.5 | 3.2 | 6.9 | 6 |
91-591-1-22 | 10x11 | 150 | 20.2 | 21.8 | 9.7 | 7.3 | 3.6 | 7.7 | 6 |
91-593-1-22 | 12x13 | 170 | 23.0 | 24.8 | 11.8 | 8.2 | 4.2 | 8.6 | 6 |
91-595-1-22 | 14x15 | 190 | 26.5 | 29.5 | 13.7 | 9.0 | 4.7 | 9.4 | 6 |
91-598-1-22 | 16x18 | 210 | 29.5 | 33.5 | 15.7 | 9.9 | 5.4 | 10.7 | 6 |
91-599-1-22 | 17x19 | 230 | 31.5 | 33.5 | 15.9 | 10.3 | 5.4 | 11.2 | 6 |
